Click here and fill out the form, and we will contact you to arrange a demonstration, either digital, at your premises or at our TROX Academy in Jaren, where you can experience the system live on our demonstration wall.

TROX Ox provides you with a noticeable indoor climate and long-lasting operation. You benefit from lower life-cycle costs, satisfied users and a solution ready for future requirements.

Wireless installation makes the job easier. Less cabling, faster commissioning and fewer sources of error, saving both time and money.

With the TROX Configurator, you can plan your system digitally and get an overview of all components before installation.

• Simplification of the entire planning process.


• Clear visualisation of the system solution.


• Easy connection to the control unit.


• More functionality with fewer interfaces.


• Data utilisation for tenders, quotations, commissioning and monitoring.

Less installation work thanks to simplified system setup and automatic detection of system components.

• Always up-to-date web tool


• No additional software installations.


• Registration and use via the myTROX customer portal.


• User-friendly interface.


• Wireless communication between room controllers, system controllers and wall-mounted sensors.


• LumenRadio's patented Mira mesh technology.


• Complete projects in a time- and cost-efficient manner.

The intuitive TROX Ox user interface makes it easy to configure, monitor, operate, customise and maintain the system.

• Access via digital web server on any PC or special display.


• Quick system configuration based on data from TROX CONFIGURATOR.


• Transparent system – open for the future.


• Intuitive operating concept for easy optimisation.


• Reliable and highly efficient operation.

The system controller is the central control element for TROX Ox. It controls the entire system and all connected subsystems, and is also available with a touch screen as an optional extra.

It offers higher-level system functions such as room-related time programmes, alarm management, reports and trends, as well as central specifications such as higher-level regulation and control tasks. Connection to BMS systems can be made via BACnet IP.

Communication between SC and FAM-W (wireless field application module) at the upper field level takes place via an encrypted wireless connection.

Communicates wirelessly from room to room and with system controllers, or via Radioduct if the rooms are difficult to reach.

• Upgrade an old VAV damper without replacing the damper (can be used independently of TROX dampers)
• Lower energy consumption
• Perfect for refurbishment.
• Users can easily adjust the temperature in the room themselves.
• 1 app for users and 1 app for adjustment.
• Ready for further expansion to BMS systems.



Wireless/wired control panel with built-in temperature sensor, humidity sensor and CO2 sensor. Adjustable for room temperature settings.

Wireless communication to FAM-W room controller with 7-years battery life. Wired version communicates via Modbus-RTU.

Sensor for installation in ceiling diffuser (wired) or on wall (wireless/wired).

For ceiling: X-Sens TPDM measures supply air temperature, room temperature and detects presence via PIR.

Wired with network cable and communicates via Modbus.

For walls: X-Sens-TH W/C wireless/wired sensor unit with built-in temperature and humidity sensor (CO₂ sensor optional). Wireless communication to FAM-W room controller with 7-years battery life. Wired version communicates via Modbus-RTU.

The adapter is used to connect components that do not have a network cable plug and is available in three versions:

Serial connection of RJ45 connection to spring connection, for Modbus-communicating devices.

RJ45 connection to spring connection.

Serial connection of RJ45 connection to RJ12 connection (for TROX accessories with order code J6).

Wireless actuator for radiators for regulating heat output on radiators.

Up to 4 actuators can communicate wirelessly with FAM-W. Battery life 7 years.

Fits valve types with 30 x 1.5 mm threads, and various adapters are available on request.

Modern buildings place high demands on IT security and stable operation. TROX Ox has been developed with this as standard.

• AES-128 encrypted communication
• Robust mesh network that connects automatically.
• Full BACnet support for easy integration with supervisory BMS systems.
• Support, service and follow-up.



Would you like to see how TROX Ox works in practice? Book a demonstration or get a presentation tailored to your project. Fill in the form below and we will contact you regarding a demonstration.

We are happy to answer your questions. We have compiled answers to the most frequently asked questions in our FAQ.
